Technical Characteristics
|
| Frequency | 50/60 Hz |
| Switching current (ohmic/inductive) | max. 5 A |
| Switching current at cos φ = 0.6 | max. 3 A |
| Relative humidity (without condensation) | 0…65 % (without condensation) |
| Extension unit input | with 230 V extension unit inputs for up and down |
| Colour | not applicable |
| Material | Plastic/metal |
|
|
| Insertion depth | 32 mm |
| Claw guidance installation depth | 32 mm |
| Housing installation depth | 22 mm |
| Installation mode | with spreader claws |
| Screw terminals (max.) | 2 x 1,5/1 x 2,5 mm² |
| Number of substations | unlimited |
| Connection | circuiting of extension units push-buttons for blinds, blind inserts, key push-buttons for blinds |
|
|
| Load cable length | max. 100 m |
| Cable length, extensions | max. 50 m |
| Change-over time for change of direction | < 0,6 s |
| Operating temperature | -5…45 °C |
|
|
| Application, usage | Blind control, KNX radio- operating systems |
| Main design line | Electronics platform |
Attachments
Zusätzliche Parameter
| Kategorie: | SMARTHOME |
|---|---|
| Gewicht: | 0.07 kg |
| Material: | Duroplastic, Metal |
| Voltage: | operating 230 V~ |
| Connection: | with screw terminals |
| Temperature: | operating -5 ... +45`C |
| Frequency: | 50/60 Hz |
