Characteristics
| Design to | according to DIN EN 60603-7-5 |
|
|
|
| Rated voltage | 72 V DC |
| Rated current | 0,5 A |
|
| Transmission bandwidth | max. 250 MHz |
| Shield contact resistance | 100 mΩ |
| Signal contact resistance | 20 mΩ |
| Colour code A and B | according to TIA/EIA-568-B.2 |
|
|
| Insertion depth | 31 mm |
| Installation mode | without spreader claws |
|
|
|
| Conductor Ø | 0,4…0,63 mm (AWG 26-22) |
|
|
|
| Protection index IP | IP20 |
|
|
| Operating temperature | -40…70 °C |
| Application, usage | Communication technology |
| Main design line | Communication technology |
Attachments
Zusätzliche Parameter
| Kategorie: | MODULE |
|---|---|
| Gewicht: | 0.117 kg |
| Design: | Berker S.1/B.3/B.7, Berker Q.1/Q.3/Q.7/Q.9, Berker K.1/K.5, Berker R.1/R.3/R.8 |
| ? Communication technology / Multimedia: | Data communication |
| Brand: | Berker |
