KNX thermostat with colour display, integrated bus coupling unit, KNX
Technical characteristics
Fixing mode
- flush-mounting
Functions
- switching of scenes (1..8) possible
- operating mode heating, cooling or heating/cooling can be selected
- switching PI-control (PWM) or switching 2-point control can be selected
- heating type warm water heating, warm water underfloor heating, electric heating, electric underfloor heating or split unit can be selected
- cooling type cooling ceiling, convector fan or split unit can be selected
- comfort, standby, night-time reduction, frost/heat protection operating mode switchable via scene
- with keylock
- with holiday switching
- with frost protection function
- operating modes heating, cooling, heating/cooling or background heating and additional heating/cooling can be selected
- control modes switching PI-control (PWM), continuous PI control or switching 2-point control can be selected
- heating types warm water heating, warm water underfloor heating, electric heating, electric underfloor heating, split unit or adjustable via object
Controls and indicators
- Operation via sensitive touch control surface
- display of set or actual temperature
- screen saver
- LC display with symbol display
- time and date display
- to display and initiate actions
Main electric features
| Auxiliary voltage: | 24 V DC |
| Operating voltage over bus: | 21...32 V DC |
| Current consumption(operation): | 25 mA |
| Bus current consumption(data transfer): | max. 10 mA |
Screen
| TFT screen size: | 1,93 ″ |
Materials
| RAL colour: | RAL 9005 - jet black |
| Material: | Thermoplastic |
Dimensions
| Insertion depth: | 32 mm |
| Dimensions of display (W x H): | 38,28 x 30,26 mm |
| Width: | 71 mm |
Installation mode
- with spreader claws, for flush-mounted and hollow-wall mounting, for single mounting, for vertical mounting
Connection
- with additional connection for external floor temperature sensor/remote sensor
- with integral bus coupling unit
- bus connection via connecting terminal
Equipment
- for heating and/or cooling mode
- heating or cooling possible in 2 stages
- for individual single room temperature control
- control parameter for heating/cooling unit pre-set
Safety
- protection index IP20
Use conditions
| Operating temperature: | -5…45 °C |
| Storage/transport temperature: | -20…70 °C |
| Energy efficiency class: | IV (2%) |
- comfort, standard and night temperature
- temperature measurement via internal and/or connectable temperature sensor with average determination
- additional connection for external temperature sensor
Attachments
Zusätzliche Parameter
| Kategorie: | MODULE |
|---|---|
| Gewicht: | 0.082 kg |
| Material: | Thermoplastic |
| Colour: | Black |
| Profession / Application: | KNX - control systems |
| Installation: | in-wall installation |
| Temperature: | operating -5 ... +45`C |
