Change-over switch for lock cylinders with earth contact
Technical Characteristics
| Type of control unit | Key |
| Fixing mode | surface-mounting |
|
|
| Nominal voltage | 250 V |
| Rated voltage | 250 V AC |
| Switching current | 16 AX (200 W Self Ballasted Lamp (SBL)) |
| Material | Plastic/metal |
| Depth | 40,2 mm |
| Height | 71 mm |
| Width | 71 mm |
| Installation mode | without spreader claws, for screw fastening |
| Connection terminals | according to IEC 60669-1 |
| Connection terminals | according to VDE 0632-1 |
| Type of connection | Screw connection |
|
|
|
|
|
| Differentiation characteristic 2 - Sales | with earth contact |
| Protection index IP | IP44 |
| Application, usage | Light control |
| Main design line | Splash-protected flush-mounted IP44 |
Attachments
Additional parameters
| Category: | MODULES |
|---|---|
| Weight: | 0.098 kg |
| Material: | Duroplastic, Metal |
| ? Protection index IP: | IP44 |
| Profession / Application: | Light control, for master-key systems, for lock cylinder |
| Configuration: | 2-pole off, change-over contact |
| Type of control unit: | Key |
| Voltage: | nominal 250V |
| Electric current: | switching current 16 A |
| Connection: | screw connection, with screw terminals |
| Connection terminals: | according to IEC 60669-1, according to VDE 0632-1 |
| Installation: | without spreader claws, for screw fastening, surface-mounting |
| Control and signalling elements: | no |
