    Push-button 4-gang wireless Quicklink, Berker Q.1/Q.3/Q.7/Q.9, anthracite matt

    Not rated
    Brand: Berker
    Availability Currently unavailible
    Delivery offer
    Code: 85648126
    260,36 € / pcs 215,17 € excl. VAT
    Push-button 4-gang wireless Quicklink, Berker Q.1/Q.3/Q.7/Q.9, anthracite matt
    Not rated
    Brand: Berker
    Push-button 4-gang wireless Quicklink, Berker Q.1/Q.3/Q.7/Q.9, anthracite matt
    Technical Characteristics

    Functions
    • ETS additional functions: +6 scenes, 1 button control up/down, operating mode on/off, dimming value, brightness display, push-button, status display, forced control
    • Functions for the push-button operation areas up/down or left/right can be freely configured as receiver for controlling the connected load and as transmitter for remote control of a blind, for example
    • reset function (to factory setting)
    • Configurable transmission and/or reception behaviour
    • scene saving lockable
    • quicklink functions: switching, dimming, blind, 2 scenes, time switching, NO contact push-button, memory

    Controls and indicators
    • operating areas configurable as one or two-area operation
    • with configuration and function button

    Connectivity
    Radio protocol KNX Radio
    Receiver category 2

    Power
    Radio transmission power < 10 mW

    Measurement
    Relative humidity (without condensation) 0…65 % (without condensation)

    Materials
    Colour of design line anthracite
    RAL colour RAL 7021 - Black grey
    Material / workmanship lacquered
    Material thermoplastic
    Surface appearance velvety

    LED control
    LED with configuration and function LEDs, LED application module/insert compatibility display

    Connection
    • integration in the KNX radio/TP gateway, surface-mounted, into the KNX TP system

    Settings
    • toolless quicklink configuration using buttons and LED display

    Equipment
    Number of radio channels 4
    Number of quicklink links max. 20 transmitter/receiver
    Transmitter duty cycle 1 %
    • switch-on brightness level for each operating area on configuration with dimmer insert, power failure proof, storable

    Safety
    • with dismantling protection

    Use conditions
    Operating temperature -5…45 °C
    • low intrinsic energy requirement

    Identification
    Application, usage Light control, KNX radio- operating systems
    Main design line Berker Q.1/Q.3/Q.7/Q.9
    Secondary design line(s) Berker Q.1, Berker Q.3, Berker Q.7, Berker Q.9



    Attachments

    85648126_Data_Sheet

    Additional parameters

    Category: MODULES
    Weight: 0.094 kg
    Design: Berker Q.1/Q.3/Q.7/Q.9
    Material: Thermoplastic
    Colour: Anthracite matt
    Surface: Velvet
    ? Light control: Switches / push-buttons, Dimmers
    Profession / Application: Light control
    Temperature: operating -5 ... +45`C
