Intermediate switch module, light control
Rocker switches
Technical Characteristics
| Type of control unit | single rocker |
| Fixing mode | surface-mounting |
| Switching angle | 3,5 ° |
|
|
| Nominal voltage | 250 V |
| Rated voltage | 250 V AC |
| Switching current | 10 AX (100 W Self Ballasted Lamp (SBL)) |
| Material | Plastic/metal |
| Surface appearance | matt |
| Depth | 41,6 mm |
| Insertion depth | 19,5 mm |
| Height | 71 mm |
| Width | 71 mm |
| Installation mode | without spreader claws, low installation depth, for screw fastening |
| Connection terminals | according to IEC 60669-1 |
| Connection terminals | according to VDE 0632-1 |
| Type of connection | Quickconnect |
|
|
|
| Protection index IP | IP20 |
| Application, usage | Light control, HVAC control |
| Main design line | Light control |
Attachments
Additional parameters
| Category: | MODULES |
|---|---|
| Design: | Berker S.1/B.3/B.7, Berker Q.1/Q.3/Q.7/Q.9, Berker K.1/K.5, Berker R.1/R.3/R.8 |
| Material: | Duroplastic, Metal |
| Type: | Cradle switches |
| ? Light control: | Switches / push-buttons |
| Inserts: | Switches / push-buttons |
| Voltage: | nominal 250V |
| Connection: | plug-in connection |
| Installation: | in-wall installation |
| Type of instrument switch: | no |
-
Technický_list_spínač_1_pólový_řazení_1
-
Technický_list_přepínač_střídavý_řezení_6_do_dutých_stěn
-
Technický_list_přepínač_střídavý_řazení_6
-
Technický_list_křížový_přepínač_řazení_7
